Fuente Gigabyte P750BS 80 Plus Bronze (GP-P750BS)

Descripción

P750BS

Especificaciones

• Model

  GP-P750BS

• Type

  Intel Form Factor ATX 12V

• PFC

  Active PFC (>0.9 typical)

• Input Voltage

  200-240 Vac

• Input Current

  6 A

• Input Frequency

  60-50 Hz

• Output Capacity

  750W

• Dimensions

  150 x 140 x 86 mm

• Fan Type

  120mm Fluid Dynamic Bearing (FDB) Fan

• 80 PLUS

  Bronze (230V EU)

• Efficiency

  88% at typical load

• MTBF

  >100,000 hours

• Protections

  OVP/OPP/SCP/UVP/OCP/OTP

• Power Good Signal

  100-150ms

• Hold Up Time

  >16ms

• Cable Type

  Embossed, All black

• Connectors

  ATX/MB 20+4 Pin x 1 : 600mm*1
  CPU/EPS 4+4 Pin x 2 : 600mm+150mm*1
  PCI-E 6+2 Pin x 4 : 500mm+150mm*2
  SATA x 4 : 500mm+150mm+150mm+150mm*1
  SATA x 3 + Peripheral x1 : 500mm+150mm+150mm+150mm*1
