Mercusys MW300UH

Especificaciones

Wireless

Wireless Standards



IEEE 802.11n, IEEE 802.11g, IEEE 802.11b



Frequency



2.400 - 2.4835 GHz



Signal Rate



11n: Up to 300 Mbps (Dynamic)11g: Up to 54 Mbps (Dynamic)11b: Up to 11 Mbps (Dynamic)



Reception Sensitivity



300M: -68 dBm@10% PER270M: -68 dBm@10% PER144M: -71 dBm@10% PER130M: -71 dBm@10% PER54M: -74 dBm@10% PER11M: -86 dBm@8% PER6M: -90 dBm@10% PER1M: -94 dBm@8% PER



Transmission Power



≤20 dBm (EIRP)



Wireless Security



WEP, WPA/WPA2, WPA-PSK/WPA2-PSK

Hardware

Dimensions (W X D X H)



4.46 × 2.51 × 0.85 in. (without antennas)4.46 × 3.96 × 7.92 in. (with vertical antennas) 113.2 × 63.8   × 21.7 mm  (without antennas)113.2 × 100.5 × 201.1 mm(with vertical antennas)



Interfaces



Micro USB 2.0



Antenna Type



External

Others

Certifications



CE, ROHS



Package Contents



300 Mbps High Gain Wireless USB Adapter (MW300UH)Quick Installation GuideResource CDUSB Cable (Micro USB to USB A)



Environment



Operating temperature: 0⁰C ~ 40⁰C (32⁰F ~ 104⁰F)Storage temperature: -40⁰C ~ 70⁰C (-40⁰F ~ 158⁰F)Operating humidity: 10% ~ 90% Non-CondensingStorage humidity: 5% ~ 90% Non-Condensing



System Requirements



Windows 10/8.1/8/7/XP (32/64 bit)
