Descripción



CPE610

5GHz 300Mbps 23dBi Outdoor CPE

  • Up to 300Mbps on 5GHz wireless data rates

  • 23dBi high-gain directional 2×2 MIMO antenna and a dedicated metal reflector, ideal for long-distance application

  • Excellent beam directivity, improved latency and noise cancellation

  • Innovative snap-lock parts make for fast assembly and a sturdy structural design keeps CPE610 stable even in strong winds

  • Durable IP65 weatherproof enclosure along with 15 kV ESD and 6 kV lightning protection ensures all-weather suitability

  • TP-Link Pharos MAXtream TDMA technology improves throughput, capacity and latency performance

  • Pharos Control gives administrators a free, centralized management system

  • AP / Client / Bridge / Repeater / AP Router / AP Client Router (WISP) operation modes

  • Passive PoE supports to allow flexible deployment and convenient installation

Especificaciones

CARACTERÍSTICAS DE HARDWARE

Procesador

Qualcomm 560MHz CPU, MIPS 74Kc

Memoria

64MB DDR2 RAM,8MB Flash

Interface

1 10/100Mbps Shielded Ethernet Port (LAN/POE)
1 Reset Button

Fuente de alimentación

Passive Power over Ethernet via LAN (+4,5pins; -7,8pins)
Voltage range: 16-27VDC

Consumo de Poder

7.41 W
Note: When deployed using Passive PoE, the power drawn from the power source will be higher by some amount depending on the length of the connecting cable.

Dimensiones (An x Pr x Al)

366 x 280 x 207 mm (14.4 x 11.0 x 8.1 in.)

Dimensiones

360 x 280 x 207 mm (14.4 x 11.0 x 8.1 in.) (No mount)

Ganancia de la Antena

23dBi

Ancho de haz de antena

9°(Azimuth), 7°(Elevation)

Protección

15KV ESD Protection
6KV Lightning Protection

Recinto

Material: Outdoor PC stabilized plastic
Weatherproof: IP65 water and dust proof design

CARACTERÍSTICAS INALÁMBRICAS

Estándares inalámbricos

IEEE 802.11a/n

Protocolo propietario

TDMA Mode (with Pharos MAXtream enabled)

Velocidades inalámbricas

Up to 300Mbps (40MHz,Dynamic)
Up to 144.4Mbps (20MHz,Dynamic)
Up to 72.2Mbps (10MHz,Dynamic)
Up to 36.1Mbps (5MHz,Dynamic)

Frecuencia

5.15~5.85GHz

Potencia de Transmision

Max. 29dBm/790mW (Adjustable power by 1dBm)

FUNCIONES DE SOFTWARE

Modos de funcionamiento

AP / Client / Bridge / Repeater / AP Router / AP Client Router (WISP Client)

configuración de la red

WAN: Static/Dynamic/PPPoE/L2TP/PPTP
LAN: Static/Dynamic/DHCP
Forwarding: DMZ/ALG/UPnP/Virtual Server/Port Trigger
Security: SPI Firewall/ Ping Forbidden/VPN/DoS Protection
Access Control
Static Routing
Bandwidth Control
IP & MAC Binding

Configuraciones inalámbricas

Pharos MAXtream TDMA Technology
Selectable Channel Width: 5/10/20/40MHz
Auto Channel Selection
Transmit Power Control
Dynamic Frequency Selection(DFS)
WDS Enable/Disable
Security: WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP) Encryption,
64/128/152-bit WEP Encryption
SSID Broadcast Enable/Disable
Multi-SSID with VLAN Tagging(AP Mode only)
Distance/ACK Timeout Setting
Wireless MAC Address Filter
Wireless Advanced:
Beacon Interval/RTS Threshold/Fragmentation Threshold/DTIM Interval/AP Isolation/Short GI/Wi-Fi Multimedia

Gestión

Discovery and Remote Management via Pharos Control application
HTTP/HTTPS Web-based management
System log
SNMP Agent(v2c)
Ping Watch Dog
Dynamic DDNS
SSH Server

Herramientas de sistema

Indicators:Signal Strength/Noise/Transmit CCQ/CPU/Memory
Monitors: Throughput/Stations/Interfaces/ARP/Routes/WAN/DHCP
Spectrum Analyzer
Speed Test
Ping
Traceroute

Optimizaciones a nivel de sistema

Optimized IGMP Snooping/Proxy for multicast applications
Hardware watch dog

CARACTERÍSTICAS DEL ADAPTADOR POE

Dimensiones(Al x An x Pr)

85.8×43.9×29.7 mm

Interfaces

1 AC Jack with Earth Ground
1 10/100Mbps Shielded Ethernet Port (Power + Data)
1 10/100Mbps Shielded Ethernet Port (Data)

Botón

Remote Reset Button

LED de estado de energía

Green

Aporte

100-240VAC, 50/60Hz

Producción

24VDC, 0.5A Max
+4, 5pins; -7, 8pins. (Support up to 60m Power over Ethernet)

Eficiencia

>84.29%

Certificaciones

CE/FCC/UL/IC/GS/PSB/C-tick/SAA/S-Mark/KC-mark

OTROS

Certificación

CE, FCC, RoHS, IP65

contenidos del paquete

Outdoor Wireless CPE
24V 0.5A Passive PoE Adapter
Pole Mounting Straps
AC Power Cord
Installation Guide

Requisitos del sistema

Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 10, Windows 8, Windows 7, MAC OS, NetWare, UNIX or Linux.
Note: We recommend you to use one of following Web browsers for an improved user experience: Google Chrome, Safari, and Firefox. IE browsers are not recommended.

Ambiente

Operating Temperature: -40℃~70℃ (-40℉~158℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~95% non-condensing
