Gigabyte B550M K (AM4)

Descripción

B550M K

• Compatible con los procesadores AMD Ryzen™ 5000 Series/ Ryzen™ 5000 G-Series/ Ryzen™ 4000 G-Series y Ryzen™ 3000 Series
• DDR4 sin búfer ECC/no ECC de doble canal, 4 DIMM
• Ranura x16 preparada para PCIe 4.0 Ultra Durable™
• Conectores duales NVMe PCIe 4.0/3.0 M.2 ultrarrápidos
• Condensadores de audio de alta calidad y protección contra ruido de audio para una máxima calidad de audio
• LAN GbE con gestión de ancho de banda
• DisplayPort y HDMI traseros para compatibilidad con múltiples pantallas
• Smart Fan 5 cuenta con múltiples sensores de temperatura y cabezales de ventilador híbridos con FAN STOP
• Diseño de resistencias anti-azufre

Especificacione

• Procesador

  1. AMD Socket AM4, support for: AMD Ryzen™ 5000 Series/ Ryzen™ 5000 G-Series/ Ryzen™ 4000 G-Series and Ryzen™ 3000 Series Processors

  (Please refer "CPU Support List" for more information.)

• Chipset

  1. AMD B550

• Memoria

  1. 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory

  2. Support for DDR4 4733(O.C.) / 4600(O.C.) / 4400(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C) / 3400(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules

  3. Dual channel memory architecture

  4. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules*
     * ECC memory (ECC mode) support varies by CPU

  5. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules

  6. Support for Extreme Memory Profile (XMP) memory modules

  (Please refer "Memory Support List" for more information.)

• Gráfica Integrada

  Integrated Graphics Processor:

  1. 1 x DisplayPort, supporting a maximum resolution of 5120x2880@60 Hz
     * Support for DisplayPort 1.4 version, HDCP 2.3, and HDR.

  2. 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
     * Support for HDMI 2.1 version, HDCP 2.3, and HDR.

  Maximum shared memory of 16 GB

• Audio

  1. Realtek® Audio CODEC

  2. High Definition Audio

  3. 2/4/5.1/7.1-channel
     * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.

• LAN

  1. Realtek® GbE LAN chip (1 Gbps/100 Mbps)

• Zócalos de Expansión

  1 x PCI Express x16 slot, integrated in the CPU:

  1. AMD Ryzen™ 5000 Series*/3000 Series Processors support PCIe 4.0 x16 mode
     * Actual support may vary by AMD CPU's specification.

  2. AMD Ryzen™ 5000 G-Series/4000 G-Series Processors support PCIe 3.0 x16 mode

  1 x PCI Express x1 slot, integrated in the Chipset:

  1. Supporting PCIe 3.0 x1 mode

• Interfaz de almacenamiento

  1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2280 SSDs:

  1. AMD Ryzen™ 5000 Series/3000 Series Processors support SATA and PCIe 4.0 x4/x2 SSDs

  2. AMD Ryzen™ 5000 G-Series/4000 G-Series Processors support SATA and PCIe 3.0 x4/x2 SSDs

  1 x M.2 connector (M2B_SB), integrated in the Chipset, supporting Socket 3, M key, type 2280 SSDs:

  1. Supporting PCIe 3.0 x2 SSDs

  4 x SATA 6Gb/s connectors, integrated in the Chipset:

  1. Support for RAID 0, RAID 1, and RAID 10

• USB

  CPU:

  1. 4 x USB 3.2 Gen 1 ports on the back panel

  Chipset:

  1. 2 x USB 3.2 Gen 1 ports available through the internal USB header

  2. 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header)

• Conectores Internos E/S

  1. 1 x 24-pin ATX main power connector

  2. 1 x 8-pin ATX 12V power connector

  3. 1 x CPU fan header

  4. 1 x system fan header

  5. 2 x M.2 Socket 3 connectors

  6. 4 x SATA 6Gb/s connectors

  7. 1 x front panel header

  8. 1 x front panel audio header

  9. 1 x USB 3.2 Gen 1 header

  10. 1 x USB 2.0/1.1 header

  11. 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)

  12. 1 x Clear CMOS jumper

• Panel E/S Trasero

  1. 1 x PS/2 keyboard/mouse port

  2. 1 x DisplayPort

  3. 1 x HDMI port

  4. 4 x USB 3.2 Gen 1 ports

  5. 4 x USB 2.0/1.1 ports

  6. 1 x RJ-45 port

  7. 3 x audio jacks

• Controlador E/S

  1. iTE® I/O Controller Chip

• Monitorización Hardware

  1. Voltage detection

  2. Temperature detection

  3. Fan speed detection

  4. Fan fail warning

  5. Fan speed control
     * Whether the fan speed control function is supported will depend on the cooler you install.

• BIOS

  1. 1 x 128 Mbit flash

  2. Use of licensed AMI UEFI BIOS

  3. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

• Otras Características

  1. Support for APP Center
     * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
     @BIOS
     EasyTune
     Smart Backup
     System Information Viewer

  2. Support for Q-Flash

  3. Support for Xpress Install

• Bundled Software

  1. Norton® Internet Security (OEM version)

  2. LAN bandwidth management software

• Sistema Operativo

  1. Support for Windows 11 64-bit

  2. Support for Windows 10 64-bit

• Formato

  1. Micro ATX Form Factor; 24.4cm x 24.4cm

• Observaciones

  1. Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website.

  2. Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP. If drivers are available from the vendors, we will update them on the GIGABYTE website.
