Consulte nuestros mejores precios en Ubiquiti y Mikrotik
Punto de acceso WiFi 6 AX3000 para placa de pared
Wi-Fi 6 de doble banda : 2402 Mbps en 5 GHz y 574 Mbps en 2,4 GHz.
Múltiples puertos con flexibilidad PoE : 4 puertos Gigabit (1 PoE de entrada, 1 PoE de paso)
Baja latencia e interferencia : MU-MIMO, OFDMA y 1024-QAM garantizan un alto rendimiento para su red.
Fácil instalación y uso : compatible con PoE 802.3af/at para una instalación flexible y con Omada SDN para una configuración con un solo clic.
Funciones avanzadas : Admite gestión centralizada, red mallada y roaming sin interrupciones.
Conexión Wi-Fi completa en la habitación con más conexiones : admite más de 120 conexiones simultáneas ** y cubre hasta 50 m² (600 ft²) * para una conectividad inalámbrica fiable y amplia.
--------------------------------------------------------------------------------------------------------
Especificaciones
| HARDWARE FEATURES | |
|---|---|
| Interface | • Uplink: 1× Gigabit Ethernet Port • Downlink: 3× Gigabit Ethernet Ports (One port supports PoE out. The PoE out feature requires 802.3at PoE+ input. The maximum power output for POE pass-through is 10.5 W (EU version) or 10 W (US version), based on laboratory testing.) |
| Physical Security Lock | No |
| Button | Reset, LED |
| Power Supply | 802.3af/at PoE |
| Max. Power Consumption | • EU: 12W (802.3at PoE, PoE Out off) • US: 12.6W (802.3at PoE, PoE Out off) |
| Dimensions ( W x D x H ) | 143 × 86 × 42.6 mm (5.6 × 3.4 × 1.7 in) |
| Antenna | 2 Dual-Band Antennas • 2.4 GHz: 2× 3 dBi • 5 GHz: 2× 5 dBi |
| Mounting | Wall Plate Mounting (Kits included) |
| Management Features | |
|---|---|
| Omada App | Yes |
| Centralized Management | • Omada Hardware Controller • Omada Software Controller • Omada Cloud-Based Controller |
| Cloud Access | Yes. Require the use of an Omada controller. |
| Email Alerts | Yes |
| LED ON/OFF Control | Yes |
| Management MAC Access Control | Yes |
| SNMP | v1, v2c, v3 |
| System Logging Local/Remote Syslog | Local/Remote Syslog |
| SSH | Yes |
| Web-based Management | HTTP/HTTPS |
| L3 Management | Yes |
| Multi-site Management | Yes |
| Management VLAN | Yes |
| Zero-Touch Provisioning | Yes. Require the use of an Omada controller. |
| WIRELESS FEATURES | |
|---|---|
| Coverage | 50㎡(600 ft²)*** |
| Concurrent Clients | 120+△ |
| Wireless Standards | IEEE 802.11ax/ac/n/g/b/a |
| Frequency | 2.4 GHz and 5 GHz |
| Signal Rate | • 5 GHz: Up to 2402 Mbps • 2.4 GHz: Up to 574 Mbps |
| Wireless Functions | • 16 SSIDs (Up to 8 SSIDs on each band) • Enable/Disable Wireless Radio • Automatic Channel Assignment • Transmit Power Control (Adjust Transmit Power on dBm) • QoS(WMM) • Seamless Roaming§ • Beamforming • Rate Limit • Load Balance • Airtime Fairness • Band Steering • Reboot Schedule • Wireless Schedule • RADIUS Accounting • MAC Authentication • Wireless Statistics • Static IP/Dynamic IP |
| Wireless Security | • Captive Portal Authentication§ • Access Control • Wireless Mac Address Filtering • Wireless Isolation Between Clients • VLAN • Rogue AP Detection • 802.1X Support • WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise |
| Transmission Power | • CE: <20 dBm (2.4GHz, EIRP) <23 dBm (5GHz band1 & 2, EIRP) <26 dBm (5GHz band3, EIRP) • FCC: < 21 dBm (2.4 GHz) < 21 dBm (5 GHz) |
| OTHERS | |
|---|---|
| Certification | FCC, RoHS |
| Package Content | • AX3000 Wall Plate WiFi 6 Access Point EAP655-Wall • Installation Guide |
| System Requirements | Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows 11, Linux |
| Environment | • Operating Temperature: 0–40 ℃ (32–104 ℉) • Storage Temperature: -40–70 ℃ (-40–158 ℉) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing |
