Access Point TP-Link Omada EAP773

1× 10G Ethernet Port

Reset

802.3at PoE or 12V/2.5A DC

Notice: Due to the software update, the power supply has been updated from 802.3bt to 802.3at.

• 24.05 W (For PoE);

• 20.92 W (For DC)

8.7 × 8.7 × 1.3 in (220 × 220 × 32.5 mm)

• 2.4 GHz: 2× 4.0 dBi

• 5 GHz: 2× 5.0 dBi

• 6 GHz: 2× 5.0 dBi

1 × 4.0 dBi, Bluetooth 5.2

*Firmware update may be required.

Ceiling / Wall Mounting (Kits Included)

140㎡(1500 ft²)§

380+**

IEEE 802.11 a/b/g/n/ac/ax/be

6 GHz, 5 GHz, and 2.4 GHz

574 Mbps (2.4 GHz) + 2880 Mbps (5 GHz) + 5760 Mbps (6 GHz)†

• MLO‡

• 4K-QAM‡

• Seamless Roaming(802.11k/v/r)

• MU-MIMO (2*2 DL/UL MU-MIMO)‡

• HE320‡

• Mesh△

• BSS Coloring‡

• OFDMA‡

• Load Balance

• Band Steering

• Beamforming

• Airtime Fairness

• Multiple SSIDS:24(8 on each band)

• Wireless Schedule

• Reboot Schedule

• QoS(WMM)

• Rate Limit

• Static IP/Dynamic IP

• RADIUS Accounting

• MAC Authentication

• Captive Portal Authentication△

• Access Control

• Maximum number of MAC Filter: 4,000

• Wireless Isolation Between Clients

• VLAN

• Rogue AP Detection

• WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise

< 20 dBm (2.4 GHz, EIRP)

< 23 dBm (5 GHz, band 1&band 2, EIRP)

< 28 dBm (5 GHz, band 3, EIRP)

< 23dBm (6 GHz, EIRP)

Yes

• Omada Cloud-Based Controller

• Omada Hardware Controller (OC300)

• Omada Hardware Controller (OC200)

• Omada Software Controller

Yes. Require the use of an OC300, OC200, Omada Software Controller, or an Omada Cloud-Based Controller.

Yes

Yes

Yes

v1, v2c, v3

Yes

Yes

CE, FCC, RoHS, IC

• EAP773

• Installation Guide

• Ceiling/Wall Mounting Kits

Note: Power Adapter is NOT included.

• Operating Temperature: 0 °C–40 °C (32 °F–104 °F);

• Storage Temperature: -40 °C–70 °C (-40 °F–158 °F);

• Operating Humidity: 10%–90% non-condensing;

• Storage Humidity: 5%–90% non-condensing;
