Archer AX55
Router AX3000 Gigabit Wi-Fi 6 doble banda
-
La próxima generación: Wi-Fi 6 Gigabit—2402 Mbps en 5 GHz y 574 Mbps en la banda de 2,4 GHz garantizan una transmisión más fluida y descargas más rápidas.
-
Conecte más dispositivos—la tecnología OFDMA aumenta 4 veces la capacidad para permitir la transmisión simultánea a más dispositivos.
-
Latencia ultra-baja—permite juegos y videollamadas con mayor capacidad de respuesta.
-
Cobertura Wi-Fi ampliada—cuatro antenas externas de alta ganancia y tecnología Beamforming se combinan para extender Wi-Fi fuerte y confiable en toda su casa.
-
TP-Link HomeShield—seguridad mejorada que defiende contra las últimas amenazas cibernéticas.
-
Duración mejorada de la batería—Target Wake Time ayuda a sus dispositivos a comunicarse más mientras consumen menos energía.
-
Compatible con Alexa—controle su router a través de comandos de voz y haga su vida más inteligente y más fácil con Amazon Alexa.
Especificaciones
|
INALAMBRICO
|
|
Estándares
|
Wi-Fi 6
IEEE 802.11ax/ac/n/a 5 GHz
IEEE 802.11ax/n/b/g 2.4 GHz
|
|
Velocidad WiFi
|
AX3000
5 GHz: 2402 Mbps (802.11ax, HE160)
2.4 GHz: 574 Mbps (802.11ax)
|
|
Rango WiFi
|
3 Bedroom Houses
4× Fixed High-Performance Antennas
Multiple antennas form a signal-boosting array to cover more directions and large areas
Beamforming
Concentrates wireless signal strength towards clients to expand WiFi range
High-Power FEM
Improves transmission power to strengthen signal coverage
|
|
Capacidad WiFi
|
High
Dual-Band
Allocate devices to different bands for optimal performance
OFDMA
Simultaneously communicates with multiple Wi-Fi 6 clients
Airtime Fairness
Improves network efficiency by limiting excessive occupation
DFS
Access an extra band to reduce congestion
4 Streams
Connect your devices to more bandwidth
|
|
Modos de trabajo
|
Router Mode
Access Point Mode
|
|
HARDWARE
|
|
Procesador
|
Dual-Core CPU
|
|
Puertos ethernet
|
1× Gigabit WAN Port
4× Gigabit LAN Ports
|
|
Soporte USB
|
1× USB 3.0 Port
Supported Partition Formats:
NTFS, exFAT, HFS+, FAT32
Supported Functions:
Apple Time Machine
FTP Server
Media Server
Samba Server
|
|
Botones
|
Wi-Fi/WPS Button
Power On/Off Button
Reset Button
|
|
Energía
|
12 V ⎓ 2 A
|
|
SEGURIDAD
|
|
Cifrado WiFi
|
WPA
WPA2
WPA3
WPA/WPA2-Enterprise (802.1x)
|
|
Seguridad de la red
|
SPI Firewall
Access Control
IP & MAC Binding
Application Layer Gateway
HomeShield Security
Real-Time IoT Protection
Malicious Site Blocker
Intrusion Prevention System
DDoS Attack Prevention
Home Network Scanner
|
|
Red de invitados
|
1× 5 GHz Guest Network
1× 2.4 GHz Guest Network
|
|
Servidor VPN
|
OpenVPN
PPTP
|
|
SOFTWARE
|
|
Protocolos
|
IPv4
IPv6
|
|
Kits de servicio
|
HomeShield
Learn More>
|
|
OneMesh™
|
OneMesh™ Supported
Without replacing your existing devices or buying a whole new WiFi ecosystem, OneMesh™ helps you create a more flexible network that covers your entire home with TP-Link OneMesh™ products.
Learn More>
All OneMesh Products>
|
|
Controles parentales
|
HomeShield Parental Controls
Custom Profiles
Professional Content Filter Library
Family Time
Bedtime
Off Time
Time Rewards
Family Online Time Ranking
Pause the Internet
Weekly and Monthly Reports
|
|
Tipos de WAN
|
Dynamic IP
Static IP
PPPoE
PPTP
L2TP
|
|
Calidad de servicio
|
QoS by Device
|
|
Cloud Service
|
Auto Firmware Upgrade
OTA Firmware Upgrade
TP-Link ID
DDNS
|
|
NAT Forwarding
|
Virtual Servers
Port Forwarding
Port Triggering
DMZ
UPnP
|
|
IPTV
|
IGMP Proxy
IGMP Snooping
Bridge
Tag VLAN
|
|
DHCP
|
Address Reservation
DHCP Client List
Server
|
|
DDNS
|
TP-Link
NO-IP
DynDNS
|
|
Gestión
|
Tether App
Webpage
Check Web Emulator>
|
|
OTRO
|
|
Requisitos del sistema
|
Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser
Cable or DSL Modem (if needed)
Subscription with an internet service provider (for internet access)
|
|
Certificaciones
|
FCC, CE, RoHS
|
|
Ambiente
|
Operating Temperature: 0℃~40℃ (32℉ ~104℉)
Operating Humidity: 10%~90% non-condensing
|
|
DATOS DE PRUEBA
|
|
Potencia de transmisión WiFi
|
CE:
<20dBm(2.4GHz)
<23dBm(5.15GHz~5.35GHz)
<30dBm(5.47GHz~5.725GHz)
FCC:
<30dBm(2.4GHz & 5.15GHz~5.825GHz)
|
|
Sensibilidad de recepción WiFi
|
5GHz:
11ac VHT20_MCS0:-96dBm, 11ac VHT20_MCS8:-75dBm
11ac VHT40_MCS0:-94dBm, 11ac VHT40_MCS9:-70dBm
11ac VHT80_MCS0:-91dBm, 11ac VHT80_MCS9:-67dBm
11ac VHT160_MCS0:-88dBm, 11ac VHT160_MCS9:-63dBm
11ax HE20_MCS0:-96dBm, 11ax HE20_MCS11:-66dBm
11ax HE40_MCS0:-93dBm, 11ax HE40_MCS11:-63dBm
11ax HE80_MCS0:-91dBm, 11ax HE80_MCS11:-61dBm
11ax HE160_MCS0:-87dBm, 11ax HE160_MCS11:-58dBm
2.4GHz:
11ac VHT20_MCS0:-96dBm, 11ac VHT20_MCS8:-74dB
11ac VHT40_MCS0:-94dBm, 11ac VHT40_MCS9:-70dB
11ax HE20_MCS0:-96dBm, 11ax HE20_MCS11:-66dBm
11ax HE40_MCS0:-93dBm, 11ax HE40_MCS11:-63dBm
|
|
FÍSICO
|
|
Dimensiones (Al x An x Pr)
|
10.2 × 5.3 × 1.5 in
(261.1 × 134.5 × 41.0 mm)
|
|
contenidos del paquete
|
Wi-Fi Router Archer AX55
Power Adapter
RJ45 Ethernet Cable
Quick Installation Guide
|
