Archer C80
Router Inalámbrico MU-MIMO Inalámbrico AC1900
- Wi-Fi 802.11ac Wave2 – 1300 Mbps en la banda de 5 GHz y 600 Mbps en la banda de 2.4 GHz
- Tecnología 3 × 3 MIMO – transmite y recibe datos en tres transmisiones para emparejarse sin problemas.
- Mayor cobertura de Wi-Fi – la tecnología Beamforming ofrece una conexión inalámbrica altamente eficiente.
- MU-MIMO – para ayudar a tus dispositivos a lograr un rendimiento óptimo al hacer que la comunicación sea más eficiente.
- Gestión personalizada – las funciones avanzadas como el Control parental, la Red de invitados y el Control de acceso proporcionan herramientas individualizadas para la gestión de la red.
- Conexión inteligente – Smart Connect dirige a los clientes a la banda menos congestionada y Airtime Fairness optimiza el uso del tiempo.
-----------------------------------------------------------------
Especificaciones
|
INALAMBRICO
|
|
Estándares
|
Wi-Fi 5
IEEE 802.11ac/n/a 5 GHz
IEEE 802.11n/b/g 2.4 GHz
|
|
Velocidad WiFi
|
AC1900
5 GHz: 1300 Mbps (802.11ac)
2.4 GHz: 600 Mbps (802.11n)
|
|
Rango WiFi
|
3 Bedroom Houses
4× Fixed High-Performance Antennas
Multiple antennas form a signal-boosting array to cover more directions and large areas
Beamforming
Concentrates wireless signal strength towards clients to expand WiFi range
|
|
Capacidad WiFi
|
Medium
Dual-Band
Allocate devices to different bands for optimal performance
3×3 MU-MIMO
Simultaneously communicates with multiple MU-MIMO clients
Airtime Fairness
Improves network efficiency by limiting excessive occupation
|
|
Modos de trabajo
|
Router Mode
Access Point Mode
|
|
HARDWARE
|
|
Procesador
|
1.2 GHz CPU
|
|
Puertos ethernet
|
1× Gigabit WAN Port
4× Gigabit LAN Ports
|
|
Botones
|
WPS/Wi-Fi Button
Power On/Off Button
Reset Button
|
|
Energía
|
US Version
12 V ? 1.5 A
EU Version
12 V ? 1 A
|
|
SEGURIDAD
|
|
Cifrado WiFi
|
WPA
WPA2
WPA3
WPA/WPA2-Enterprise (802.1x)
|
|
Seguridad de la red
|
SPI Firewall
Access Control
IP & MAC Binding
Application Layer Gateway
|
|
Red de invitados
|
1× 5 GHz Guest Network
1× 2.4 GHz Guest Network
|
|
SOFTWARE
|
|
Protocolos
|
IPv4
IPv6
|
|
OneMesh™
|
OneMesh™ Supported
Without replacing your existing devices or buying a whole new WiFi ecosystem, OneMesh™ helps you create a more flexible network that covers your entire home with TP-Link OneMesh™ products.
Learn More>
All OneMesh Products>
|
|
Controles parentales
|
URL Filtering
Time Controls
|
|
Tipos de WAN
|
Dynamic IP
Static IP
PPPoE
PPTP
L2TP
|
|
Calidad de servicio
|
QoS by Device
|
|
Cloud Service
|
OTA Firmware Upgrade
TP-Link ID
DDNS
|
|
NAT Forwarding
|
Port Forwarding
Port Triggering
DMZ
UPnP
|
|
IPTV
|
IGMP Proxy
IGMP Snooping
Bridge
Tag VLAN
|
|
DHCP
|
Address Reservation
DHCP Client List
Server
|
|
DDNS
|
TP-Link
NO-IP
DynDNS
|
|
Gestión
|
Tether App
Webpage
Check Web Emulator>
|
|
OTRO
|
|
Requisitos del sistema
|
Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser
Cable or DSL Modem (if needed)
Subscription with an internet service provider (for internet access)
|
|
Certificaciones
|
FCC, CE, RoHS
|
|
Ambiente
|
Operating Temperature: 0°C~40°C (32°F ~104°F)
Storage Temperature: -40°C~70°C (-40°F ~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
|
|
DATOS DE PRUEBA
|
|
Potencia de transmisión WiFi
|
CE:
<20dBm(2.4GHz)
<23dBm(5.15GHz~5.25GHz)
FCC:
<30dBm(2.4GHz & 5GHz)
|
|
Sensibilidad de recepción WiFi
|
5GHz:
11a 6Mbps:-98dBm, 11a 54Mbps:-78dBm
11ac VHT20_MCS0:-98dBm, 11ac VHT20_MCS8:-72dBm
11ac VHT40_MCS0:-92dBm, 11ac VHT40_MCS9:-68dBm
11ac VHT80_MCS0:-89dBm, 11ac VHT80_MCS9:-64dBm
2.4GHz:
11g 6Mbps:-97dBm, 11a 54Mbps:-77dBm
11n VHT20_MCS0:-97dBm, 11n VHT20_MCS8:-72dBm
11n VHT40_MCS0:-92dBm, 11n VHT40_MCS9:-67dBm
|
|
FÍSICO
|
|
Dimensiones (Al x An x Pr)
|
8.5 × 4.6 × 1.26 in
(215 × 117 × 32 mm)
|
|
contenidos del paquete
|
Wi-Fi Router Archer C80
Power Adapter
RJ45 Ethernet Cable
Quick Installation Guide
|
